IP65 Full Color Outdoor Led Display Building Wall Screen P4 Waterproof
LED Display Panel Outdoor are used in various public places, you can find them everywhere, like highway, subway, shopping mall, exterior of stores, commercial center. most of them are used for advertising, signage, background.
Features of Led Wall Screen Display Outdoor
1. IP65 protection, protect from dust and moisture.
2. Wide viewing angle(H: 140°; V:140°).
3. Waterproof design, keep working, reduce the failure rate of running in the rain
4. Long life span(>100,000 Hours).
5. Competitive factory price, with guaranteed quality.
Led Display Specification
| OutdoorLED Display | |||||||
| Model No. | P2.5 | P3.0 | P4 | P5 | P6 | P8 | P10 |
| Pixel Pitch(mm) | 2.5 | 3.076 | 4 | 5 | 6 | 8 | 10 |
| LED Type | SMD1415 | SMD1415 | SMD1921 | SMD2727 | SMD3535 | SMD3535 SMD3535 | |
| Module Dimensio (W*H)(mm) | 320x160 | 320x160 | 320x160 | 320x160 | 320x160 | 320x160 | 320x160 |
| Cabinet Dimension (W*H)(mm) | 960x960 | 960x960 | 960x960 | 960x960 | 960x960 | 960x960 | 960x960 |
| Cabinet Material | Magnesium Alloy | ||||||
| Cabinet Weight (Kg) | 28 | ||||||
| Ingress Protection (Front/Rear) | IP65 | ||||||
| Brightness(nits) | 5500~6500 | ||||||
| Viewing Angle | H:140°Vi140 | ||||||
| Color Temperature | 3200~9500K | ||||||
| Max Power Consumption (W/m²) | 750 | 750 | 750 | 750 | 750 | 800 | 800 |
| Average Power Consumption (W/m²) | 300 | 300 | 300 | 300 | 300 | 350 | 350 |
| Maintenance Method | Rear Maintenance(Our c Series Support Front Maintenance) | ||||||
| Gray Level | 14bit | ||||||
| Refresh Rate (Hz) | 3200~3840Hz | ||||||
| Waterproof Level | IP65 | ||||||
| Operating Temperature | -20°~60° | ||||||
| Life Time (Hours) | 100000 | ||||||
| Warranty | 3-5years | ||||||
2 years quality guarantee for all parts.
Experienced engineers and technicians provide solutions to all kinds of question.
Providing free and spare accessories, such as power and data cables.
Free remote control debuggine serice if you need.
Installation guidance by experienced technicians.
|
|
