Outdoor street pole led screen P4 Street lighting pole led display

Ask Lasest Price
Brand Name :	HSCX
Model Number :	P3.84
Certification :	CE ROHS FCC
Payment Terms :	L/C, T/T
Delivery Time :	10-20 workdays

Add to Cart

Product Details
Company Profile

Outdoor street pole led screen P4 Street lighting pole led display

Customized Outdoor Waterproof Full Color Double sided Street Light Pole Display Screen

Widely Applications by LED Lampost Screens

1.Government commercial avenue , Commercial center street road. Park sightseeing project introduction, Local lighting display project. Community bulletin led display ,bus station, construction display project, airport corridor project, railway, metro station exist projects.

2.Exhibition center, museum, library. Gymnasium, stadium ,theater , university , middle school, hospital, bank, and so on.

3.Hotel, restaurant. Mountain villa, commercial buildings.

4. Shopping mall, Sales lobby ,Chain store.

Specifications

1,High brightness,easy installation

2, Energy saving,Easy maintenance

3, Advanced dot adjusting

4, 3G,4G, WIFI control

Super brightness full color LED billboard advertising

Function and Technology characters:

1. Show all kinds of word,text,graph,pictures,flashes,video,2-dimension,3-dimension carton and any other formats with your PC does synchronously.

2.Different signal resources input are acceptable,such as TV,HCTV,S-video,NTSC/PAL,DVI,AVI,VGA,SDI,MOV,MPG,HD-SDI,ect.

3,Self-adjustment function

Automatically adjusts outdoor LED display brightness to suitable level through outdoor environment condition

4,It can be used in advertisement,stage,stadium,exhibition,TV-Show,mansion video wall,shopping mall,banks,schools,bus station,airport,gym,market,factories,monitoring certers,hospitals,bars etc.

Parameters:

Outdoor LED pole display screen parameters
Model	P2.5	P3	P3.84	P4	P4	P5
Pixel	2.5mm	3mm	3.84mm	4mm	4mm	5mm
Model Size	320*160mm	192*192mm	200*200mm	256*128mm	320*160mm	320*160mm
Pixel Density	160000dot/m2	111111dot/m2	67708dot/m2	62500dot/m2	62500dot/m2	40000dot/m2
Cabinet size	480960mm 6401280mm	384768mm 5761152mm 768*1536mm	6001200mm 8001600mm	5121024mm 7681536mm	480960mm 6401280mm 800*1600mm	480960mm 6401280mm 800*1600mm
Scan Mode	1/16S	1/13S	1/13S	1/10S	1/10S	1/8S
Maximum power	1075W	1000W	950W	900W	900W	900W
Average power	358W	320W	310W	300W	300W	300W
Refresh frequency	1920-3840HZ
Brightness	5000-6000cd/m2
control	Cloud platform PC/3G/4G/WIFI
Environment temperature range	-20-60℃
Humidity(working)	10-95%RH
Input Voltage	AC110-240V±15% 50-60HzVoltage
Installation method	Lifting/Side Installation

Feature:

1. Double side or Single side pole light cabinet for your option.

2. Standard color : Sliver, Black, White

3. Energy saving , power consumption lower.

4. With a iron clasp fixed tightly to light pole.

5. Dynamic LED Panel Design based on customer request.

6. White side lighting make whole light box vivid different from normal type

7. It is strong enough to use in the outdoor environment, even the bad weather. 8. Our cabinet designed with waterproof parts for outdoor use. 9. Aluminum or Iron material, normally light box will have connect parts among corner , and there will be a gap at the corner. But in our welding technical,we welding cabinet corner inside , so this will make no gap and storage water. 10. Inside the cabinet, we also have waterproof belt to help avoid the water. 11. LED & power supply are waterproof, IP65 certification. 12. Our products with CE , RoHS EMC FCC Certification which could prove our quality.

Additional functions:
1. Energy efficiency: all led screen will have auto adjust brightness and auto turn on/off functions, no need people to do these work by manual.
2. With high refresh rate and meet high-speed camera’s monitor requests, the led screen should be more smooth for displaying.
3. Brightness: auto adjust brightness or add commands for adjusting brightness in the certain time, will not effect the traffics.
4. Estimate Cost:
Power consumption: 0.3KW/set * 16 hours/day *30days/month
Data flow: USD30 /month
Maintainence: USD45/set/month

Unique advantages:

1) Simple structure in linear type ,easy in installation and maintation.
2) Adopting advanced famous brand of IC and LED for the modules.
3) Thick iron cabinet for IP65 waterproof.
4)High brightness while facing the sunshine.
5) 2 years warranty.

Presales and After sales Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the display, training how to use the software.

* Engineers available to service overseas.

More inquires please emails us or Whatsapp 86 136 7013 8771
