Front maintenance led display cabinet, when there is any failure in the display, open the flip of the display from the front, you can see the internal structure of the display , so as to carry out inspection and maintenance. Normally, after the flip of the display is opened, it is Fixed by pneumatic rod. Install the front-maintained cabinet against the wall, with holes for screwing on the back of the cabinet, or use a lifting ring.
Our Features:
1. Front access/Front service LED Display
2. High brightness, visible even with direct sunshine
3. High water proof and dust proof, IP65 both front and rear side
4. Having good lighting accordance and no mosaic
5. Getting vivid effect within any position of the viewing range
6. Any LED in died pixel can be respectively repaired, which reduce the cost of the display maintenance.
IP65 Weather Rate
The led display special waterproof function protects it from water and dust when it is intalled in outside areas .High IP grade rating IP65 ensures great quality outputs in different weather conditions .
Good Heat Dissipation
HSLED display each cabinet inside has cooling fans .With heat dissipation fan ,it has good heat dissipation performance, The number of fans can be increased accoding to the size of led cabinet ,it can ensure the ventilation and heat dissipation according to change of the specific environment and climate .
Excellent Visual Display
HSLED Screens are equipped with high-quality LEDs and Driving IC to ensure high refresh rate and high contrast ratio.The Refresh rate is up to 7680Hz and high definition image quality with 5000:1. The brightness reaches to 1000 Nits that provide the viewers with perfect display effect.
Specification:
| Model | P2.6 | P3 | P4 | P5 | P6.67 | P8 | P10 |
| Pixel Pitch | 2.6mm | 3mm | 4mm | 5 mm | 6.67mm | 8mm | 10mm |
| Pixel composition | SMD1415 | SMD1415/SMD1921 | SMD1921 | SDM1921/ SMD2727 | SMD2727 | SMD2727/SMD3535 | SMD3535 |
| Module size | 250/250mm/192*192mm320*160mm |
| Pixel density | 147456pixel | 105688 pixels | 62500 pixels | 40000 pixels | 22500 pixel | 15625 pixel | 10000 pixel |
 |
| Max power | |
| Average power | |
| Visual angle | |
| Max Brightness | |
| Refresh Rate | |
| IC driving (scan ) | 1/16 S | 1/13 S | 1/ 10 S | 1/8 S | 1/6 S | 1/5 S | 1/2 S |
| IP rate | |
| Maintenance method | |
P2.6/P3/P4/P5/P6/P10mm front repairing access/ front service / front maintenance front open outdoor LED video display
A LED advertising screen from HSLED has many benefits:
Deliver eye-catching messages
Unrivalled clarity and vivid colours
Extremely reliable and sustainable
Design your own content with our user-friendly software
Unlimited textual and graphical options
Cost-effective medium with high return on your investment
Our Services:
OUR COMPANY provides on site product installation, debugging and maintenance service for our LED display. Such as:
1. After-sales service:
1) Service principles: response in time, solve problems as soon as possible and ensure the use.
2) Service period: In the Maintenance period of the LED screen body, free of all maintenance charges; After Maintenance period, only charge the material costs fees free of manual work fees.
3) Service scope: If the users find any problem that cannot be solved, please contact with our company, we can response in 24 hours. In order to shorten the maintenance time, Our Company will deploy some spare parts such as power and chips etc.
4) Under normal use and storage, Our Company will be responsible for the equipment.
2. Pre-sales service:
1) Our company can arrange professionals to conduct site installation and debugging in strict accordance with the requirements of the schemes and the original manual. If there is any special requirement, it is necessary to make changes of part installation scheme, we will coordinate with users. Our company can ensure the consistence of completion time and contracted time. Any problems caused by natural factors or man-made, we will discuss with client to find solutions.
2) Our company can train the users based on the manual. The training include system use, system maintenance and equipment protection.
FAQ:
Q1. Can you assign engineer to our site to guide the installation if we require?
A1:Yes. We have qualified and experienced engineers who are ready to service for you.
Q2: Where is it used for?
A2: Indoor & rental use. Widely used for backdrop of staging event, rental business, liveshow, concert, etc.
Q3: Can it play HD video?
A3: Yes, it can realize HD video function with Novastar controlling system.
Q4: What's the controlling system?
A4: Our standard controlling system for this model is Novastar. Also support other controlling system, like Linsn, etc.
Q5: How about the size of project?
A5: Please offer the size with "width by height" of project. We wil offer the suitable solution for your project size. I will appreciate it if any drawing files about installation offered.
